The Phantom Pumps PL-3 Centrifugal, Self-Priming Pump

The PL-3 Pump

The PL-3 is a multifaceted, self-priming pump that’s perfectly suited for sumps, buried tanks, tankers, industrial effluent treatment, and many other applications. It can also be set to many low- and high-pressure specifications and can fit a variety of pressure and flow applications.

The Benefits & Advantages of the PL-3

This pump exemplifies the advantages of thoughtful design and superior performance, offering a plethora of benefits to its users. With unique features such as an external shim-less adjustment for maintaining optimal performance, a replaceable wear plate for increased pump lifespan, and multi-vane impellers for maximum efficiency, the PL-3 pump is adept at navigating the challenges of diverse applications while minimizing downtime.

Exceptional Performance

The PL-3 delivers excellent flow rates and performance characteristics. It can efficiently manage solids up to 3 inches and caters to high-head and high-volume pumping applications.

Removable Cover Plate

The PL-3 features a removable cover plate, providing easy and direct access to the pump interior. This feature significantly reduces service and maintenance time, minimizing downtime.

External Shim-Less Adjustment

The PL-3 boasts a unique external shim-less adjustment feature. This allows for easy adjustment of the clearance between the wear plate and the impeller, maintaining the pump's peak performance without requiring complete disassembly.

Multi-Vane Impellers

Equipped with multi-vane impellers, the PL-3 delivers maximum efficiencies. It can handle solids and slurries effectively, making it an ideal choice for various demanding applications.

Replaceable Wear Plate

The PL-3 features a replaceable wear plate. This design extends the lifespan of the pump and reduces maintenance costs by allowing the wear plate to be replaced without the need for full pump disassembly.

Dual Protection System

The PL-3 incorporates a dual protection system that includes a seal leak detector and a bearing temperature sensor. This system enables early detection of potential issues and prevents significant failures.

Back Pull-Out Design

The PL-3 utilizes a back pull-out design to ensure ease of maintenance. This design allows for easy pump disassembly for repairs or inspections while leaving the casing in the piping.

Automatic Air Release

The PL-3 is equipped with an automatic air release system during priming to ensure smooth and efficient operation. The pump does not require a foot valve as it primes and reprimes fully automatically.

Versatile Applications

The PL-3 series is a true workhorse with exceptional versatility across industries and applications. With their ability to handle a wide range of fluids, including corrosive chemicals, abrasive slurries, and viscous liquids, the PL-3 series ensures optimal performance and productivity in diverse environments.

Pump Data

Net Weight:
183kg (404lbs)
Shipping Weight:
205kg (452lbs)
Impeller Diameter:
222.25mm (8 3⁄4”)
RPM range:
650 to 2150 RPM
Max. Solids:
63.5mm (2 1⁄2”)

Self-Priming Head

650 RPM 1.5m (5ft) - 750 RPM 1.8m (6ft)
850 RPM 2.4m (8ft) - 950 RPM 3.0m (10ft)
1050 RPM 4.0m (13ft) - 1150 RPM 4.9m (16ft)
1250 RPM 5.5m (18ft) - 1350 RPM 5.8m (19ft)
1450 RPM 6.4m (21ft) - 1550 RPM 6.4m (21ft)
1650 RPM 6.7m (22ft) - 1750 RPM 6.7m (22ft)
1850 RPM 7.6m (25ft) - 1950 RPM 7.6m (25ft)
2050 RPM 7.6m (25ft) - 2150 RPM 7.6m (25ft)

Materials of Construction

Check the net positive suction head (NPSH) before using this table

Component
STD
CI / 316SS
CI / CD4MCU
CI / ADI
CI / HCI
ADI
316SS
CD4MCU
Casting
A48CL30
ADI
316SS
CD4MCU
Impeller
A60-40-18
316SS
CD4MCU
ADI
HCI
ADI
316SS
CD4MCU
Wear Plate
A48CL30
316SS
CD4MCU
ADI
HCI
ADI
316SS
CD4MCU
Cover Plate
A48CL30
ADI
316SS
CD4MCU
Bearing Housing
A48CL30
ADI
316SS
CD4MCU
Seal Plate
A48CL30
316SS
CD4MCU
ADI
HCI
ADI
316SS
CD4MCU
Flap Valve
Neoprene
Viton
Impeller Shaft
ANSI4140HT
ANSI17-4PH
Seal Sleeve
ANSI4140HT
ANSI17-4PH
Flanges
A48CL30
ADI
316SS
CD4MCU
O Rings
Buna
Viton
Mechanical Seal
316SS, Buna, Tungs/Titanium Carbide
316SS, Viton, Tungs/Titanium Carbide
